Features
1.The bag length is free of manual setting, the equipment may automatically detect and set the length. Thus, it can used to pack material with different length.
2.Simplified mechanic gearing, easy to maintain, little vibration, little wear and “long life”.
3.The main control circuit takes PLC develop, digital screen display and controlled by transducer. Perfect inter face between operator and machine. Integrated, direct and convenient operation.
4.The capacity and the length of bag take double frequency converter control with stepless speed shift and wide adjustment. It can match well with the former working producer of production line.
5.Height sensitive respond photoelectric device can follow automatically and accurately.
6.Independent temperature control for each sealer to make the beautiful bags,and tight sealing and suitable for a wide variety of flexible packing material. Thus its usaged will be more wide.
7. This machine can be equipped with gas charging device and production date code system according to client’s packaging requirements.
Advantages
1.Dual frequency conversion control, bag length freely adjustable
2.It with digital screen, full CNC adjustment, convenient and flexible operation.
3.Anti-cut material can be increased with the device, security will be guaranteed.
4.Fault self-diagnosis function, clear failure display, Positioned stop function, without sticking knife or wasting film.
5.Fully Automatic, you just need to put the food on the conveyor is ok. It can send the food into packing machine directly. It will save labour, save time , good packing effect,big capacity.
6.LG-250B is the best choice to reduce package material and its cost.As we know,the package material is consumable items so that cost of package material for a long time is higher than the packing machine.The design of LG-250B can save package material to cost down.
Technical Data
Model | LG-250B |
Film Width | Max. 350mm |
Bag length | 65-190 OR 90-330mm |
Bag width | 30~110mm |
Film Diameter | Max. 320mm |
Product height | Max.40mm |
Packing speed | 40~230 bags/min |
Power supply | 220V,50/60 H Z,2.6 KW |
Machine size | (L)3770X(W)670X(H)1450mm |
Machine weight | 880Kg |
